GPS/WAAS chart plotter with built-in chirp fish finder
The GP-1971F is a high-performance marine GPS chart plotter combined with an integrated CHIRP fish finder. It features a 9-inch sunlight-readable multi-touch display, built-in GPS/WAAS positioning, and advanced sonar technologies for accurate navigation and fish detection. The unit is suitable for recreational, commercial fishing, and small vessel operations.
Product Details
FEATURES
GPS/WAAS CHART PLOTTER with built-in CHIRP FISH FINDER
Navigation & Display
- 9-inch wide-color multi-touch LCD display
- High-brightness screen suitable for direct sunlight
- Built-in 72-channel GPS/WAAS receiver
- Supports detailed marine charts (chart cards optional)
- Multiple display modes: chart plotter, fish finder, radar overlay, AIS, instruments
- Intuitive touch gestures and slide-out menus
Fish Finder & Sonar
- Built-in TruEcho™ CHIRP fish finder
- Supports CHIRP and conventional sonar
- Dual-frequency and dual-range operation
- ACCU-FISH™ for fish size estimation
- RezBoost™ signal processing for improved target separation
- Bottom discrimination for seabed identification
Connectivity & Integration
- NMEA 2000 interface
- NMEA 0183 interface
- Wireless connectivity for compatible radar and mobile device mirroring
- Compatible with AIS, autopilot, and marine instruments
User Convenience
- Two MicroSD card slots for charts and data storage
- Screenshot capture function
- Compact, modern design suitable for helm mounting
SPECIFICATION
Display Unit
Screen Type: GP-1971F: 9" Wide Color TFT LCD
Screen Resolution: WVGA 800 x 480 pixels
HD 1280 x 720 pixels * For production in 2022 and later
GPS Antenna: Internal Antenna
Display Modes: Chart Plotter, Fish Finder, Radar (connection to the 1st Watch Wireless Radar DRS4W required), AIS (connection to AIS sensor required), Instruments (Nav Data, Engine, Wind, Fuel tank), Autopilot (connection to the FURUNO NAVpilot-300 or 700 series required)
Language: English (US & UK), French, Spanish, German, Italian, Portuguese, Danish, Swedish, Norwegian, Finnish, Greek, Japanese.
GPS / SBAS (WAAS/EGNOS/MSAS)
Receiving Type: GPS 72 channels
WAAS 1 channel
Receiving Frequency: L1 (1575.42 MHz)
Accuracy: GPS: 10 m Max, WAAS: 5 m Max, MSAS: 7.5 m Max
Plotter
Chart: 32 GB Max., C-MAP 4D chart or Navionics chart
Memory Capacity: 30,000 points for ship's track and waypoints
1,000 planned routes (Max. 250 points per route)
5,000 quickpoints
Fish Finder
Frequency: CHIRP: 40 to 225 kHz
CW: 50/200 kHz
Transducer: 300 W or 600 W or 1 kW (Transducer dependent)
Range: 5-1, 200 m, shift :0-500 m
Modes: TruEcho CHIRP™*, RezBoost™**, ACCU-FISH™**, Bottom Discrimination**, Dual Frequency**, Dual Range** Auto gain (Fishing/Cruising), Manual gain, A-Scope, Marker Zoom, Bottom Zoom, Bottom Lock
* CHIRP dedicated transducer required
** Dual frequency CW compatible transducer required
Interface:
NMEA2000 - 1 port (Interface CAN bus)
Input: 126992, 127245, 127250, 127251, 127258, 127488, 127489, 127493, 127497, 127505, 128259, 128267, 128275, 129025, 129026, 129029, 129038, 129039, 129040, 129041, 129284, 129285, 129538, 129540, 129793, 129794, 129798, 129808, 129809, 129810, 130306, 130310, 130311, 130312, 130313, 130314, 130316, 130577, 130578, 130830, 130831, 130832, 130880
Output: 126992, 127245, 127250, 127251, 127257, 127258, 127505, 128259, 128267, 128275, 129025, 129026, 129029, 129033, 129283, 129284, 129285, 130306, 130310, 130312, 130316, 130830, 130831, 130832
NMEA0183 - 1 port
Input: DBT, DPT, DSC, DSE, GGA, GLL, GNS, HDG, HDT, MTW, MWV, RMC, ROT, RSA, THS, TLL, VBW, VDM, VHW, VTG, ZDA, PFEC (GPatt/SDmrk/SDtbd/SDtfl/pireq)
Output: AAM, APB, BOD, BWR, DBT, DPT, GGA, GLL, GNS, GSA, GSV, GTD, HDG, HDT, MTW, MWV, RMB, RMC, RTE, THS, TLL, VHW, VTG, WPL, XTE, ZDA, PFEC (SDmrk/SDtbd/SDtfl/pidat)
Other: Micro SD Card Slot x 2 (32 GB)
Others
Waterproofing: IP56
Power Supply
12-24 VDC, 1.0-0.5 A
12-24 VDC, 1.1-0.6 A * For production in 2022 and later
NMEA2000: 1 port
NMEA0183: 1 port * Software version 1.1 or later
